14 Outputs LED Traffic Lights Controller
- JC-14
- Availability: In Stock
- 14 Outputs LED Traffic Lights Controller
$70.00
14 Outputs LED Traffic Lights Controller
Specifications:
Size: 320mm x 325mm x 120mm
Input Voltage: 85V～264V AC 50Hz/60Hz
Output Current: 5A per line
Power Consumption: 10 watt
Loaded power: ≤1100W
Green Flash Time: 0-59s
Green flash frequency: 2-0.125Hz
Yellow flash frequency: 2-0.125Hz
Clock precision: 0.1 second (24 hours, 25℃)
Ambient Temperature: -40～+70℃
Ambient RH: 40%-95%
Package Dimension: 410mm x 400mm x 180mm
Volume (m3): 0.026
Quatity: 1 PCS/Carton
Gross Weight: 6.4 Kg
Applications:
14 outputs controller which control a single intersection
Specifications:
Size: 320mm x 325mm x 120mm
Input Voltage: 85V～264V AC 50Hz/60Hz
Output Current: 5A per line
Power Consumption: 10 watt
Loaded power: ≤1100W
Green Flash Time: 0-59s
Green flash frequency: 2-0.125Hz
Yellow flash frequency: 2-0.125Hz
Clock precision: 0.1 second (24 hours, 25℃)
Ambient Temperature: -40～+70℃
Ambient RH: 40%-95%
Package Dimension: 410mm x 400mm x 180mm
Volume (m3): 0.026
Quatity: 1 PCS/Carton
Gross Weight: 6.4 Kg
Applications:
14 outputs controller which control a single intersection
